How to check internet connection continuously in Xamarin

Handling the internet connection in any applications is a must if those applications interact with the network and we also must notify the user that he/she is disconnected from the internet. So In this article, I’m going to show you how to check internet connection continuously in Xamarin Forms from a single place.

Let’s Start

In this sample demo I will use Xamarin.Essentials.Connectivity.cs static class for handling internet connection changes.

1 – Install Xamarin.Essentials nuget package.

2 – In Android project

2.1 Initialize Xamarin Essentials in OnCreate() method

protected override void OnCreate(Bundle savedInstanceState)
{
     base.OnCreate(savedInstanceState);

     // Initializing Xamarin Essentials
     Xamarin.Essentials.Platform.Init(this, savedInstanceState);

     global::Xamarin.Forms.Forms.Init(this, savedInstanceState);
     LoadApplication(new App());
}

2.2 Add ACCESS_NETWORK_STATE permission in manifest file

<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android"
	android:versionCode="1"
	android:versionName="1.0"
	package="com.companyname.xfinternetstatussample">
	<uses-sdk android:minSdkVersion="21" android:targetSdkVersion="31" />
	<application android:label="XFInternetStatusSample.Android" android:theme="@style/MainTheme"></application>
	<uses-permission android:name="android.permission.ACCESS_NETWORK_STATE" />
</manifest>

3 – Create a NetworkConnectivity.cs class for handling network connections

using Xamarin.Essentials;

namespace XFInternetStatusSample
{
    public class NetworkConnectivity
    {
        private bool IsInternetConnected;

        #region Constructor

        public NetworkConnectivity()
        {
            // Register for connectivity changes, be sure to unsubscribe when finished
            Connectivity.ConnectivityChanged += OnConnectivityChanged;

            IsInternetConnected = CheckConnection();
        }

        #endregion

        #region Destructor

        ~NetworkConnectivity()
        {
            Connectivity.ConnectivityChanged -= OnConnectivityChanged;
        }

        #endregion

        #region Handle Network Connection

        public static bool CheckConnection()
        {
            var current = Connectivity.NetworkAccess;

            if (current == NetworkAccess.Internet)
                return true;
            else
                return false;
        }

        private void OnConnectivityChanged(object sender, ConnectivityChangedEventArgs e)
        {
            var access = e.NetworkAccess;
            var profiles = e.ConnectionProfiles;

            switch (access)
            {
                case NetworkAccess.Internet:

                    IsInternetConnected = true;
                    ShowInternetConnection(true);

                    break;

                case NetworkAccess.None:

                    IsInternetConnected = false;
                    ShowInternetConnection(false);

                    break;

                case NetworkAccess.Local:

                    IsInternetConnected = false;
                    ShowInternetConnection(false);

                    break;

                case NetworkAccess.Unknown:
                    System.Console.Write("A problem has occurred with your network connection.");
                    break;
                default:
                    break;
            }
        }

        private void ShowInternetConnection(bool isInternetAvail)
        {
            // Set Internet connection view in every page in header
            App.Instance.SetInternetConnectionView(isInternetAvail);
        }


        #endregion

    }
}

4 – Now, Create Instance static property in App.xaml.cs

private static App _instance;
public static App Instance
{
    get { return _instance; }
    set { _instance = value; }
}

5 – Initialize Instance static variable in constructor of App.xaml.cs

public App ()
{
    InitializeComponent();
    Instance = this;
    MainPage = new NavigationPage(new MainPage());
}

6 – Now, Initialize NetworkConnectivity.cs class in OnStart() method.

protected override void OnStart ()
{
    // Register Network Connectivity Change Event
    NetworkConnectivity networkConnectivityHelper = new NetworkConnectivity();
}

7 – Now, Coming to UI part first of all we need to create ControlTemplate for each network state in App.xaml


<!--  Page Header (InternetConnection view) Template  -->
<ControlTemplate x:Key="InternetConnTemplate">
        <StackLayout Spacing="0">

               <BoxView
                     BackgroundColor="#2196F3"
                     HeightRequest="55"
                     IsVisible="{OnPlatform Android='False',
                                               iOS='True'}" />

               <ContentPresenter />

        </StackLayout>
</ControlTemplate>

<!--  Empty Template  -->
<ControlTemplate x:Key="EmptyTemplate">
        <StackLayout Spacing="0">

               <BoxView
                    BackgroundColor="#2196F3"
                    HeightRequest="55"
                    IsVisible="{OnPlatform Android='False',
                                               iOS='True'}" />

               <ContentPresenter />

        </StackLayout>
</ControlTemplate>

 <!--  Online Template  -->
 <ControlTemplate x:Key="OnlineTemplate">
         <StackLayout Spacing="0">

               <BoxView
                    BackgroundColor="#2196F3"
                    HeightRequest="55"
                    IsVisible="{OnPlatform Android='False',
                                               iOS='True'}" />

               <Frame
                    x:Name="FrameBackground"
                    Padding="0,2,0,2"
                    BackgroundColor="#32CD32"
                    CornerRadius="0"
                    HasShadow="False">

                      <Label
                          x:Name="LabelTitle"
                          FontAttributes="Bold"
                          HorizontalOptions="CenterAndExpand"
                          Text="Internet Connected"
                          TextColor="White"
                          VerticalOptions="CenterAndExpand" />

               </Frame>

               <ContentPresenter />

         </StackLayout>
</ControlTemplate>

<!--  Offline Template  -->
<ControlTemplate x:Key="OfflineTemplate">
        <StackLayout Spacing="0">

              <BoxView
                   BackgroundColor="#2196F3"
                   HeightRequest="55"
                   IsVisible="{OnPlatform Android='False',
                                               iOS='True'}" />

              <Frame
                   Padding="0,2,0,2"
                   BackgroundColor="Red"
                   CornerRadius="0"
                   HasShadow="False">

                       <Label
                            FontAttributes="Bold"
                            HorizontalOptions="CenterAndExpand"
                            Text="No internet connection"
                            TextColor="White"
                            VerticalOptions="CenterAndExpand" />

              </Frame>

              <ContentPresenter />

         </StackLayout>
</ControlTemplate>

8 – Now, We will need to change the template at run time when the network state will change

So, Create a SetInternetConnectionView() method in App.xaml.cs If you will see, this method is called from the NetworkConnectivity.cs class.

#region Set Internet Connection View

public void SetInternetConnectionView(bool isInternetAvail)
{
     Device.BeginInvokeOnMainThread(() =>
     {
         if (isInternetAvail)
         {
              App.Current.Resources["InternetConnTemplate"] = App.Current.Resources["OnlineTemplate"];

              StartTimerFor4Second();
         }
         else
         {
              App.Current.Resources["InternetConnTemplate"] = App.Current.Resources["OfflineTemplate"];
         }
     });
}

private static void RemoveTopInternetConnView()
{
    App.Current.Resources["InternetConnTemplate"] = App.Current.Resources["EmptyTemplate"];
}

private void StartTimerFor4Second()
{
    System.Timers.Timer timer = new System.Timers.Timer();
    timer.Interval = 4000;
    timer.Enabled = true;
    timer.Elapsed += OnTimedEvent;
}

private static void OnTimedEvent(Object source, System.Timers.ElapsedEventArgs e)
{
    try
    {
         (source as System.Timers.Timer).Enabled = false;
         (source as System.Timers.Timer).Dispose();

         Device.BeginInvokeOnMainThread(() =>
         {
             RemoveTopInternetConnView();
         });
    }
    catch (Exception ex)
    {
    }
}

#endregion

State Explanation

Normal State : Empty Template shows in normal state.
Offline State : Offline Template shows when no internet connection is available.
Online State : Online Template shows when internet connection comes back.

I have used a timer for displaying online templates for only 4 seconds.

In case of no internet connection we will need to call the SetInternetConnectionView() method from the OnResume() method and Constructors of App.xaml.cs.

protected override void OnResume ()
{
     if (!NetworkConnectivity.CheckConnection())
         SetInternetConnectionView(false);
}

public App ()
{
     InitializeComponent();
     Instance = this;
     MainPage = new NavigationPage(new MainPage());

     if (!NetworkConnectivity.CheckConnection())
          SetInternetConnectionView(false);
}

9 – At last we need to set the InternetConnTemplate control template in the root page of all pages

ControlTemplate=”{DynamicResource InternetConnTemplate}”

Example
